G652D CWDM Fiber Optic Patch Cord 1x2 PVC LSZH FTTH

1530-1542nm C Band Pass Filter 1x2 CWDM Component 3 Ports Red/Blue 5G

Description of CWDM Fiber Optic Patch Cord

The C Band Red/Blue Filter Wavelength Division Multiplexer is a micro optics device based on environmentally stable thin film filter technology. It is used to separate or combine Red band wavelength signals and Blue band wavelength signals in C band range in DWDM systems. The components are characterized with wide passband, low insertion loss, high return loss, excellent environmental stability and high power handling capability.

Specification of CWDM Fiber Optic Patch Cord

Parameter		Unit	Value
Pass Band	Wavelength Range	nm	1530 - 1542 (1548 - 1560)
	Max. Insertion Loss	dB	0.6
	Typ. Insertion Loss	dB	0.4
	Min. Isolation	dB	22
	Typ. Isolation	dB	25
Reflection Band	Wavelength Range	nm	1548 - 1560 (1530 - 1542)
	Max. Insertion Loss	dB	0.5
	Typ. Insertion Loss	dB	0.3
	Min. Isolation	dB	12
	Typ. Isolation	dB	14
Min. Return Loss		dB	50
Max. Polarization Dependent Loss		dB	0.10
Typ. Polarization Dependent Loss		dB	0.05
Thermal Stability		dB/℃	0.005
Max. Optical Power (Continuous Wave)		mW	300
Max. Tensile Load		N	5
Fiber Type			SMF-28 fiber
Operating Temperature		℃	-5 to +70
Storage Temperature		℃	-40 to +85

Features of CWDM Fiber Optic Patch Cord

Low Insertion loss
Wide pass band
High Channel Isolation
High Stability and reliability
Epoxy-free on Optical Path

Application of CWDM Fiber Optic Patch Cord

Line monitoring
WDM network
Telecommunication
Fiber optical amplifier
Access network

G652D CWDM Fiber Optic Patch Cord 1x2 PVC LSZH FTTH

The reason why Choose us

1. On time delivery
2. Factory outlet
3. Large product inventory with massive production line
4. Quality guarantee
5. One to one special after-sales service

FAQ

1. Can I have a sample order of this product?
Yes, we welcome sample order for you to test and check the quality.
Mixed samples are acceptable as well.

2. How to Store the Optical Fiber Cable Properly?
Store the drum indoor before using, the drum should place sideways
not on the end.

3. What's your payment terms?
We accept T/T,L/C,Western Union,D/P etc. 30% in advance and 70%
before shipment.

4. Are you factory direct?
As a professional Cable manufacturer, specialized in Fiber Optic
Patch Cord, Fiber Optic PLC Splitter. Our products are mainly
exported to Europe, South America, and some other countries and
areas.

5. Is there any discount on the product?
We have several production promotion activities every month,
welcome to inquire.
